Pengubah Warna LED RGB Teraktivasi Gerakan – Proyek Arduino

Komponen dan Perlengkapan

	Sparkfun APDS-9960	×	1
	Kabel Jumper (umum)	×	1
	Arduino UNO	×	1
	Resistor 4.75k ohm	×	1
	LED RGB Diffused Common Cathode	×	1

Aplikasi dan Layanan Online

Arduino IDE

Tentang Proyek Ini

Proyek ini akan memungkinkan Anda memanfaatkan kekuatan gerakan Anda untuk mengontrol LED RGB. Anda memerlukan Sparkfun APDS-9960 dan LED RGB COMMON CATHODE, bukan anode. Pastikan untuk menggunakan papan Arduino 5v dengan resistor 4.7k Ohm, karena sensor ini menggunakan protokol I2C. Kemudian sambungkan seperti dalam skematik. Dari sana Anda dapat menambahkan warna custom dalam kode. Saya telah menambahkan 6 warna. Kontrol default adalah: geser ke atas untuk menyala, geser ke bawah untuk mati, geser ke kanan untuk maju ke warna berikutnya, dan kiri untuk mundur. Kode ini dapat disesuaikan untuk berbagai jenis proyek lainnya! Silakan bereksperimen dan buat proyek yang lebih luar biasa. Happy making!

Gambar produk pada breadboard:

Kode

• Kode Arduino

Kode ArduinoC/C++

#include <Wire.h> #include <SparkFun_APDS9960.h> // Pins #define APDS9960_INT 2 // Needs to be an interrupt pin // Constants int red_pin = A0; int green_pin = A1; int blue_pin = A2; int onOff_flag = 0; //Make the array to loop through int colorNumber = 0; // Global Variables SparkFun_APDS9960 apds = SparkFun_APDS9960(); int isr_flag = 0; void setup() { // Set interrupt pin as input pinMode(APDS9960_INT, INPUT); // Initialize Serial port Serial.begin(9600); Serial.println(); Serial.println(F("--------------------------------")); Serial.println(F("SparkFun APDS-9960 - GestureTest")); Serial.println(F("--------------------------------")); // Initialize interrupt service routine attachInterrupt(0, interruptRoutine, FALLING); // Initialize APDS-9960 (configure I2C and initial values) if ( apds.init() ) { Serial.println(F("APDS-9960 initialization complete")); } else { Serial.println(F("Something went wrong during APDS-9960 init!")); } // Start running the APDS-9960 gesture sensor engine if ( apds.enableGestureSensor(true) ) { Serial.println(F("Gesture sensor is now running")); } else { Serial.println(F("Something went wrong during gesture sensor init!")); } pinMode(A0, OUTPUT); pinMode(A1, OUTPUT); pinMode(A2, OUTPUT); analogWrite(A0, 0); analogWrite(A1, 0); analogWrite(A2, 0); } void loop() { if( isr_flag == 1 ) { detachInterrupt(0); handleGesture(); isr_flag = 0; attachInterrupt(0, interruptRoutine, FALLING); } if (onOff_flag == 1){ switch (colorNumber){ case 0: Serial.println("red"); analogWrite(red_pin, 255); analogWrite(green_pin, 0); analogWrite(blue_pin, 0); break; case 1: Serial.println("baby blue"); analogWrite(red_pin, 255); analogWrite(green_pin, 153); analogWrite(blue_pin, 204); break; case 2: Serial.println("dark blue"); analogWrite(red_pin, 100); analogWrite(green_pin, 0); analogWrite(blue_pin, 170); break; case 3: Serial.println("green"); analogWrite(red_pin, 0); analogWrite(green_pin, 255); analogWrite(blue_pin, 0); break; case 4: Serial.println("blue"); analogWrite(red_pin, 0); analogWrite(green_pin, 0); analogWrite(blue_pin, 255); break; case 5: Serial.println("violet"); analogWrite(red_pin, 191); analogWrite(green_pin, 0); analogWrite(blue_pin, 255); break; } } else if(onOff_flag == 0){ analogWrite(red_pin, 0); analogWrite(green_pin, 0); analogWrite(blue_pin, 0); } delay(1000); } void interruptRoutine() { isr_flag = 1; } void handleGesture() { if ( apds.isGestureAvailable() ) { switch ( apds.readGesture() ) { case DIR_UP: Serial.println("UP"); onOff_flag = 1; break; case DIR_DOWN: Serial.println("DOWN"); onOff_flag = 0; break; case DIR_LEFT: Serial.println("LEFT"); if(onOff_flag == 1){ if(colorNumber>0){ colorNumber -= 1; Serial.println(colorNumber); } else if(colorNumber < 1){ colorNumber = 5; Serial.println(colorNumber); } } break; case DIR_RIGHT: Serial.println("RIGHT"); if(onOff_flag == 1){ if(colorNumber < 5){ colorNumber += 1; Serial.println(colorNumber); } else if(colorNumber > 4){ colorNumber = 0; Serial.println(colorNumber); } } break; case DIR_NEAR: Serial.println("NEAR"); break; case DIR_FAR: Serial.println("FAR"); break; default: Serial.println("NONE"); } } }

Skematik

Sambungkan seperti yang ada.
